Soil Liquefaction Analysis for Detroit Infrastructure Projects

Q: How much does a liquefaction analysis cost for a typical Detroit building site?

Sites with complex stratigraphy or requiring multiple design earthquake scenarios may fall at the upper end.

Detroit sits at an elevation of roughly 600 feet above sea level, layered over glacial lake plains and ancient riverbeds that deposited loose, water-saturated sands across the metropolitan area. While Michigan is not known for frequent large-magnitude earthquakes, the city rests within a region where the New Madrid Seismic Zone and even distant Canadian events can transmit low-frequency ground motion capable of triggering soil liquefaction in susceptible deposits. In our experience, the combination of shallow groundwater common in former industrial corridors and uniform fine sands — often encountered below 15 feet — creates conditions that demand a rigorous liquefaction potential assessment before any deep foundation or heavy structure work proceeds. When we review borehole logs from sites near the Detroit River or along the I-75 corridor, we frequently see the classic signatures of liquefiable soils: low SPT N-values, minimal fines content, and saturation within the upper 30 feet. A proper cone penetration test provides continuous profiling through these critical layers, while we rely on standard penetration test data for the simplified procedures outlined in Youd and Idriss (2001).

Liquefaction is not just a West Coast concern — saturated loose sands in Detroit's glacial lake plains can lose strength under seismic loading from distant sources.

Process and scope

Our field methodology in Detroit typically pairs truck-mounted SPT drilling rigs with downhole sampling equipment designed to retrieve Standard Penetration Test data at 2.5-foot intervals through the potentially liquefiable strata — normally the upper 50 feet. The rig operates on compacted construction access pads or existing pavement, which is important given that many Detroit sites are brownfield parcels with variable surface conditions. Once the SPT data reaches our laboratory, we run grain-size distribution tests per ASTM D2487 on split-spoon samples to quantify fines content, because the presence of just 15 to 35 percent fines can dramatically increase a soil's cyclic resistance ratio. The analysis itself applies the simplified procedure codified in ASCE 7-22 and the 2021 International Building Code, computing the factor of safety against liquefaction at each sampled depth. For projects where foundation alternatives are being compared, we often recommend supplementing the SPT-based assessment with seismic refraction surveys to establish shear wave velocity profiles, which provide an independent measure of small-strain stiffness and help constrain the site classification per ASCE 7 Table 20.3-1.

Local ground factors

The glacially derived soils underlying Detroit's east side and downriver communities present a specific risk profile: loose fine sands and silty sands deposited in proglacial lake environments, often with groundwater within 5 to 10 feet of the surface. These units can reach thicknesses exceeding 30 feet, and when we calculate the factor of safety against liquefaction, we occasionally see values below 1.2 in the 10-to-25-foot depth range — particularly where SPT blow counts drop under 8. The consequence of liquefaction in these soils during a moderate seismic event would be loss of bearing capacity, differential settlement, and potential lateral spreading near riverbanks or canal walls. For critical facilities, even a factor of safety of 1.3 may be considered marginal, which is why our reports include post-liquefaction settlement estimates and recommendations for ground improvement — such as stone columns or compaction grouting — where the risk profile exceeds project tolerance.

Reference parameters

Parameter	Typical value
Analysis Method	Simplified procedure (Youd & Idriss 2001, updated per ASCE 7-22)
Field Test	Standard Penetration Test (SPT) ASTM D1586 at 2.5 ft intervals
Magnitude Scaling Factor	Based on site-specific probabilistic seismic hazard analysis (PSHA)
Fines Content Correction	Grain-size analysis per ASTM D6913/D7928 on split-spoon samples
Cyclic Resistance Ratio (CRR)	Adjusted for overburden stress, fines content, and aging
Cyclic Stress Ratio (CSR)	Computed using peak ground acceleration from USGS hazard maps
Depth Interval	Typically upper 50 feet, extended in deep deposits

Other technical services

Site-Specific Liquefaction Potential Evaluation

We perform SPT-based liquefaction triggering analysis for individual building sites, transportation corridors, and utility alignments in Detroit. Each evaluation includes field drilling and sampling, laboratory grain-size testing, computation of CSR and CRR profiles, and factor of safety plots for the design earthquake. The final report provides post-liquefaction settlement estimates and clear recommendations on whether ground improvement or foundation deepening is required per IBC Section 1803.5.

Liquefaction Mitigation Design Support

When our analysis identifies unacceptable liquefaction risk — common in Detroit's riverfront and industrial redevelopment zones — we support the design of mitigation measures including vibrocompaction, stone columns, and deep soil mixing. Our team develops performance specifications, reviews contractor submittals, and conducts post-treatment verification testing to confirm that target improvement ratios have been achieved.

Regulatory framework

ASCE 7-22 Minimum Design Loads and Associated Criteria for Buildings and Other Structures, 2021 International Building Code (IBC) Chapter 18, ASTM D1586-18 Standard Test Method for Standard Penetration Test (SPT), ASTM D2487-17 Standard Practice for Classification of Soils for Engineering Purposes, Youd, T.L. and Idriss, I.M. (2001) NCEER/NSF Workshop on Evaluation of Liquefaction Resistance of Soils

Quick answers

What depth range is typically evaluated for liquefaction in Detroit?

We evaluate the upper 50 feet in most Detroit projects because the loose, saturated sands deposited by glacial lakes usually occur within that interval. For deeper deposits — sometimes encountered in buried river channels — we extend the analysis to 70 feet or until we reach dense till or bedrock that is clearly non-liquefiable.

How much does a liquefaction analysis cost for a typical Detroit building site?

Does Michigan's building code require liquefaction analysis?

The Michigan Building Code adopts the 2021 IBC, which in Section 1803.5.12 requires evaluation of liquefaction potential for structures assigned to Seismic Design Category D, E, or F. While much of Detroit falls into Category C, many essential facilities, taller structures, and projects on soft soils must still be evaluated — and we recommend analysis whenever saturated loose sands are present within the upper 50 feet.

What if liquefaction risk is found — can the site still be built on?

Yes, and we guide clients through the process regularly. Options include deepening foundations below the liquefiable layer, using deep foundations such as driven piles that bypass the problem soils, or improving the ground with stone columns or vibrocompaction. The choice depends on the structure type, budget, and site constraints, and our report provides a comparative assessment of feasible alternatives.
